Asus Prime Z390M-Plus
$269.45
$269.45 Zcom Computer LTD
Payment Methods
+2
Reviews
Show all
7 years ago
ASUS PRIME Z390M-PLUS mATX Form, For Intel 8th/9th Gen CPU, LGA1151, Z390, 4XDDR4 DIMM, 2XM.2, 2XPCIE X16, 2XPCIE X2, 6XUSB, HDMI/DVI , LAN, Internal: I/O: 2XUSB3.1, 2XUSB2.0, 1X 12V RGB Header
While the Z390 is on the pricey end of motherboards, this is the cheapest of the them. If you can do without WIFI, this board has plenty of everything else. Supports all the latest hardware and faster memory works perfectly.
Product details
The best price for Asus Prime Z390M-Plus is $269.45. This is presently the cheapest offer in New Zealand. The average rating is 5.0 out of 5 from one review.
Product info
General
Chipset
Intel Z390
Design
Form factor
Micro ATX
Cooling
Passive
Processor
Socket
Intel Socket 1151-V2
64-bit processor
Yes
Compatible processors
Celeron, Core i3, Core i5, Core i7, Pentium
Number processor sockets
One
Connectors
Display Port
No
Component output YPbPr/YCbCr
No
Composite output
No
DVI
Yes
eSATA
No
Headphone output
Yes
Microphone input
1 pc
PS/2
2 pc
S/PDIF
No
HDMI
HDMI
Yes
HDMI version
1.4b
HDMI outputs
1 pc
USB Connectors
USB
Yes
USB type
USB (Type A)
USB 3.0/3.1 (Gen 1)
4 pc
USB 3.1 (Gen 2)
2 pc
Internal Connections
M.2
2 pc
Chassis fan connectors
2 pc
Internal S/PDIF
1 pc
Internal USB 2.0
4 pc
Internal USB 3.0/3.1 ports (Gen 1)
4 pc
SATA
Yes
SATA (total)
4 pc
SATA 6Gb/s
4 pc
SCSI controller
No
Image properties
Graphics card
No
Support for integrated graphics in CPU
Yes
Expansion slots
AGP slot
No
Mini-PCI
No
PCI Express Mini
No
PCI Express x1
2 pc
PCI Express x16
2 pc
PCI Express x4
No
PCI Express x8
No
PCI slots
No
PCI-X
No
PCI Express version
3.0
Features
AMD crossfire
Yes
Communication
Bluetooth
No
Ethernet connection RJ45
Yes
Network chip
Intel I219-V
Number of Ethernet connections
1 pc
Wireless network Wi-Fi
No
Compatibility
RAID controller
Yes
RAID type
0, 1, 10, 5
Graphics Card
Multiple graphics cards
Yes
Multi-GPU technology
CrossFireX
Sound Card
Sound card
Yes
Sound card chip
Realtek ALC887
Memory
Memory Type
DDR4
ECC support
No
Maximum memory
64 GB
Memory slots
4 pc
Memory speed
DDR4-2666, DDR4-2800, DDR4-2933, DDR4-3000, DDR4-3066, DDR4-3100, DDR4-3200, DDR4-3300, DDR4-3333, DDR4-3400, DDR4-3466, DDR4-3500, DDR4-3600, DDR4-3666, DDR4-3733, DDR4-3800, DDR4-3866, DDR4-4000, DDR4-4133, DDR4-4200, DDR4-4266 Mhz
Miscellaneous
Manufacturer warranty
3 Years
